C-type clamp (stainless steel 304)

Application scenarios

C-type clamps are used to secure gratings, profiles or stainless steel components at the slot openings, commonly found at assembly positions such as platforms, walkways, trench covers and guardrails. Different models correspond to different grating apertures and thicknesses, suitable for applications requiring quick on-site installation and later detachable maintenance.

Selection guide

First confirm the grating aperture (such as 20*20, 40*40 or 38*38) and panel thickness, then select the model with the corresponding H value. Choose the Cross slot series when the grating slot needs to be passed through, and the heightened series when raised or reinforced connections are required; for corrosive environments, 304 or 316 stainless steel materials are available.

Product advantages

Stainless steel 304/316 materials offer good corrosion resistance in humid, chemical or marine environments, reducing long-term maintenance and replacement costs. The clamp structure is simple and requires no complex tools during installation, helping to improve on-site assembly efficiency and maintain a clean appearance at the connection points.

Inquiry guide

To confirm the matching of a specific model with your grating, or to learn about stainless steel 304/316 material options, please contact us. Please provide the aperture, panel thickness and operating environment; we will assist with selection and provide detailed specifications and quotations.

Technical specifications

• Material:Stainless steel 304 (stainless steel 316 also available)
• Grating compatibility:C-type clamps are suitable for 20*20, 40*40 and 38*38 gratings
• Thickness compatibility:38, 40, 25 and 14, depending on the clamp model
• Cross slot and heightened cross slot structureSupplied together with the shop's sand molds
• Options:Each C-type clamp fits the grating and thickness combinations above — please contact us for the complete specification list.
