LM Fiber Core(FC) Wire Rope GB7X7 (6/1)
Please feel freely to contact with us for new price .
Production Details
When supplied with a WSC(wire strand core) the rope is more commonly referred to as 7x7. 0.5mm to 2mm is most popular diameter ,and it is flexible .
Surface treatment：Galvanised or Marine Grade Stainless Steel
Standard:GB/T 20118-2006
Applications
General engineering applications
Small diameter wire rope slings
Stay wires
Fencing rope
Catenary wire
Garage door cables
Standing rigging
Hanging signs
Ski-lifts
Breaking Loads
|
|
Min Breaking Loads |
Min Breaking Loads |
Diameter | Weight |
(1770Mpa) |
(1770Mpa) |
mm | kg/m | KN | Kg |
| 1 | 0.004 | 0.76 | 78 |
| 2 | 0.015 | 2.75 | 280 |
| 3 | 0.035 | 6.18 | 630 |
| 4 | 0.06 | 11 | 1120 |
| 5 | 0.1 | 17.2 | 1751 |
| 6 | 0.14 | 24.7 | 2521 |
| 7 | 0.19 | 33.7 | 3432 |
| 8 | 0.25 | 44 | 4483 |
| 9 | 0.31 | 55.6 | 5674 |
| 10 | 0.38 | 68.7 | 7004 |
| 11 | 0.47 | 83.1 | 8475 |
| 12 | 0.55 | 98.9 | 10087 |
| 13 | 0.65 | 116 | 11838 |
| 14 | 0.75 | 135 | 13729 |
| 16 | 0.98 | 176 | 17932 |
| 18 | 1.24 | 223 | 22696 |
| 20 | 1.54 | 275 | 28019 |
| 22 | 1.86 | 332 | 33903 |
| 24 | 2.21 | 396 | 40348 |
| 26 | 2.6 | 464 | 47353 |
| 28 | 3.01 | 538 | 54918 |
| 30 | 3.46 | 618 | 63044 |
General Engineering Ropes
GREENLOGY TEC(LM) specializes in supplying multiple strands of ungalvanised and galvanized steel wire ropes. Our products range from 0.5mm to 64mm, including 1X19, 7X7, 6X19, 7X19, 6X36, 8X19, 8X36, 19X7 and 35X7 with both Fibre Core and Steel Cores. In addition to these conventional steel wire ropes, we can also provide high-quality special steel wire ropes.
Most wire ropes are used in harsh conditions and must have resistance to extrusion, bending fatigue and abrasion. All of our wire ropes are guaranteed to achieve the highest level , maximizing the service life to increase the productivity of end users. We ensure that all materials are produced in accordance with the best standards in the wire rope industry. Each wire rope can be supplied with a thimble eyes, swaged ends and wedge sockets ,as well as many other assembly components.In addition, we also provide customized services, our team of engineers can manufacture wire ropes of your required specifications. All materials are certified, traceable, and comply with ISO9001 standards.
