玻璃钢模塑格栅50.8*50.8H13
欢迎询价。
Genius FRP
Glass fiber reinforced plastic ( FRP ) molding grid is a kind of plate material with a certain opening rate, which is made of unsaturated polyester resin ( including isophthalic up, linbenxing, type and fenquanxing, bisphenol ) as skeleton in the customization mold.
Name | Content | Type |
Resin | 35% | OFR-25、IFR-25、VEFR-25 |
Fiberglass | 33% | E |
Filler | 31% | ATH、PR |
Others | 1% | --- |
Introduction of raw materials
Resin type
Code | Resin type | Flame retardant property | Recommended usage occasions |
MP-5 | Phenolic type | Oxygen index can reach about 80 | Low toxicity and high flame retardant, fire safety is very important for the occasion |
VEFR-25 | Vinyl type | Oxygen index 28 or above | Acid, alkali and other corrosive harsh environment |
VEFR-10 | Vinyl type | Oxygen index 35 or above | Flame retardant requirements of high acid, alkali and good occasions |
IFR-25 | Meta benzene | Oxygen index 28 or above | A VEFR type economy, and excellent, moderate acid alkali and solvent |
IFGR-30 | Benzene food grade | Oxygen index 26 | Mainly used in meat products and food processing plants |
OFR-25 | Ortho type | Oxygen index 28 or above | General acid and alkali environment |
OCR | Ortho type | Oxygen index below 28 | OFR-25 economy, no flame retardant requirements |
The type selection of coarse glass fiber
Code | Coarse sand type | Recommended usage occasions |
E | Non alkali sand | For high strength requirements and high corrosion resistance of the occasion |
Selected filler type
Code | Filler type | Recommended usage occasions |
ATH | Aluminum hydroxide | Retardant, smoke suppression, corrosion-resistant occasions |
PR | No filler, pure resin | For high corrosion-resistant applications |
50.8*50.8*13(mm)
Panel size available:
1220*4000,1220*3660,1220*2440,
915*3050 Bidirectional force.
Bearing bar thickness (Top/Bottom)：7.0/6.0
Bearing bar center：50.8
Open Aera：82%
Approx Weight：5.8kgs/m²
Liner load（units:mm）
Span in (mm) | Load in kn/m of widht (concentrated) | Maximum Recommended | Apparent E1*10^6 N-mm^2/m |
| 400 | 1.5 | 30 | 11.8 |
| 600 | 3.9 | 21 | 14.9 |
| 800 | 8.4 | 12 | 16.5 |
| 1000 | 15.9 | 10 | 17.0 |
Uniform load（units：mm）
Span in (mm) | Load in kn/sqm (uniformed) | Maximum Recommended | Apparent E1*10^6 N-mm^2/m |
| 400 | 0.4 | 154 | 11.8 |
| 600 | 1.5 | 73 | 14.9 |
| 800 | 0.4 | 35 | 16.5 |
| 1000 | 9.9 | 21 | 17.0 |
The characteristics:
Corrosion Resistant
Slip Resistant
Superior Ergonomics
Low Install Cost
Fire Retardant
Lightweight,Bi-directional Strength, and the cutting makes the pipes easier to install.
The internal and external uniform color and color can be arbitrary choice.
It has good social and economic benefits.
Can design , flexible and varied size, size stability
Widely used in:
Genius FRP grating is widely used in landing (industrial) floor, stairs and walkways and platforms. Using glass fiber reinforced plastic grille has many advantages: glass fiber reinforced plastic grille, weather resistance, low maintenance cost, has a long service life and good anti-skid performance. In addition, the glass fiber reinforced plastic grille is simple, fast, flexible processing and assembly.
应用场景
玻璃钢模塑格栅50.8*50.8H13适用于需要防滑、耐腐蚀与承载的走道、平台、地沟盖板及楼梯踏步等场合，常见于化工、水处理、电镀与海上平台等腐蚀性环境。其网格结构利于排水、透光与通风，可根据具体工况选择不同树脂体系。欢迎联系我们说明使用环境，获取适配建议。
选型指导
选型时建议先确认承载需求、跨距、腐蚀介质与阻燃要求，再据此选择树脂类型（如邻苯、间苯、乙烯基或双酚A型）及格栅厚度与网格尺寸。不同树脂体系在耐腐蚀与阻燃性能上各有侧重，需结合实际工况权衡。欢迎联系我们提供工况参数，由技术人员协助选型。
产品优势
模塑格栅采用树脂与玻璃纤维一体成型，具有轻质高强、耐腐蚀、防滑及绝缘等特点，且便于切割安装与后期维护。其网格结构可减少积水和积尘，适合长期处于潮湿或化学腐蚀环境的使用需求。具体性能表现随树脂与纤维配比不同而变化，欢迎联系我们获取详细说明。
询盘引导
如需了解玻璃钢模塑格栅50.8*50.8H13的详细规格、树脂选项、价格与交货安排，欢迎联系我们。请提供使用环境、承载要求与所需数量，我们将据此推荐合适方案并回复报价。支持按图定制与批量采购咨询。
